Ubiquiti GigaBeam Plus (GBE-PLUS), 17dBm, 35dBi @ 60GHz, 1xGigabit, Bluetooth, 1+Gbps
Κωδικός e-Wireless: 1001.424

BrandUbiquiti MPNGBE-PLUS
271.99
χωρίς ΦΠΑ 219.35
Σε Απόθεμα
+
Wishlist
Αποστολές & Επιστροφές
Τρόποι πληρωμής
Γιατί e-Wireless;
Γρήγορη και ασφαλής παράδοση

Αποστέλλουμε παραγγελίες σε όλη την Ελλάδα με ΕΛΤΑ Courier και ACS

Presales και Aftersales

Για να σας λύνονται όλες οι τεχνικές απορίες

Επιστροφές εντός 14 ημερών

Αρκεί το προϊόν να μην έχει ανοιχτεί και να μην έχουν προκληθεί φθορές στην συσκευασία του

E-WIRELESS

Αναλυτική Παρουσίαση

    airMAX AC 60 GHz Radio System with True Duplex Gigabit Performance.

    GBE-Plus is a 60 GHz Radio capable of supporting 1 Gbps rates with very low latency. GBE-Plus can be used as a high throughput backhaul/edge PTP solution in WISP deployments. Housed in a outdoor industrial design, the GBE-Plus achieves significant gain improvements with an integrated Cassegrain reflector design. The GBE-Plus is easily set-up, configured and managed through the UISP dashboard and UISP™️ Mobile app via Bluetooth.

    Features:

    • Low-Interference 60 GHz Spectrum
    • 35 dBi Antenna Gain with Integrated Reflector
    • 1.5+ Gbps Bidirectional Throughput with Low Latency
    • Long Range, up to 1.5 km
    • link.ui.com Planning Support
    • Quick Setup Using the UISP™️ App via Bluetooth
    Mechanical
    DimensionsØ155 x 137 mm (Ø6.1 x 5.4")
    Weight1kg (2.2 lb)
    Enclosure MaterialsUV Resistance Polycarbonate, Stainless Steel
    Mount MaterialsMetal
    Wind Loading50 N at 200 km/h (11.24 lbf at 125 mph)
    Hardware
    ProcessorQuad-Core ARM® Cortex® A7
    Memory256 MB DDR3
    Networking Interface10/100/1000 Mbps Ethernet RJ45
    Management InterfaceEthernet In-Band
    Bluetooth
    RF ConnectionsInternal
    Max. Power Consumption11W
    Power MethodPassive PoE (Pairs 4, 5+; 7, 8-)
    Power Supply24VDC, 0.5A Gigabit PoE Adapter
    24V, 1A for using Motor Accessory
    Supported Voltage Range22 to 26VDC
    ESD/EMP ProtectionAir/Contact: ± 24kV
    Operating Temperature-40 to 60° C (-40 to 140° F)
    Operating Humidity5 - 95% Noncondensing
    CertificationsFCC, IC, CE
    LEDs
    PowerFlashing White: Bootup in Progress
    White: Not Connected to Ubiquiti® Internet Service Provider (UISP™)
    Blue: Connected to UISP
    EthernetFlashing Blue: Ethernet Traffic Detected
    60GHzBlue: Active Connection
    Software
    OSairOS®
    Operating ModesPtP as Access Point or Station
    Ubiquiti Specific FeaturesIntegrated 60 GHz Radio, Discovery Protocol
    SecurityWPA2 AES Only
    DashboardYes
    Wireless SettingsYes
    Network SettingsYes
    SystemYes
    ServicesUISP, Ping Watchdog, Web Server, SSH Server, NTP Client, System Log, Device Discovery
    ToolsAntenna Alignment Tool, Discovery Utility, Traceroute, Speed Test
    Software ManagementBluetooth Management for Easy Setup Over UISP™ App
    WEB UI
    Minimum Software RequirementsAny Modern Web Browser/iPhone/Android
    RF
    Operating Frequency*57,000 - 66,000 MHz
    * Depends on regulatory region.
    Max. Conducted TX Power17 dBm
    Channel Bandwidth2160 MHz
    Operating Channels58320, 60480, 62640, 64800 MHz
    Antenna Gain35 dBi
    BeamwidthHPOL: NaN (The Antenna is Only Vertically Polarized)
    VPOL: 3°
    Elevation: 3°
    Management Radio2400 - 2483.5 MHz
    Electrical Downtilt
