Wavertech WAC52N, 5xEthernet, 1.5dBi, 19dBm @ 2.4GHz, 2dBi, 22dBm @ 5GHz, PoE Out, 200 Clients

Περάστε πάνω απο την φωτογραφία για μεγέθυνση.

1148.001
286.00
Με ΦΠΑ 354.64
Σε Απόθεμα
+
Brand: WAVERTECH
MPN: WAC52
Τρόποι Αποστολής
Τρόποι Πληρωμής
Γιατι e-Wireless

Όλα τα προϊόντα με εγγύηση κατασκευαστή6-36 Μήνες

Ενημέρωση για την εξέλιξη της παραγγελίαςΕνημέρωση για την εξέλιξη της παραγγελίας

Επιστροφές εντός 14 ημερολογιακών ημερώνΕπιστροφές εντός 14 ημερολογιακών ημερών.

Ευελιξία στους Τρόπους πληρωμήςΕυελιξία στους Τρόπους πληρωμής

Ωράριο ΚαταστήματοςΩράριο Καταστήματος

Firmware Change LOG Here

Waver SmartOne is a reliable dual band wireless router with integrated captive portal, advanced hotspot and guest management capabilities. It features an easy to use and manage administration interface that is designed to fulfill the most demanding needs of small businesses in the hospitality industry. N-Series are ideal for small venues with internet connection speeds that do not cross the 100Mbps barrier.

FEATURES

User friendly Administration Interface for easy configuration and management

Responsive Guest Captive Portal with six fully customizable themes

Integrated Captive Portal Editor – Custom Texts, Colors, Buttons, Images, Video, Logos, Languages, Hyperlinks etc.

Multilingual guest experience (admins can translate captive portal contents to up to 140 languages)

Multiple Guest Login options: Free, Email, Facebook Login, Mobile/SMS, User/pass, QR Login and Prepaid Access

Captive portal support for external content (web images, videos, jscript, chat platforms, iframes etc.)

Custom Terms – Privacy texts and User Data retention policy settings (GDPR Compliant)

Analytical Statistics and Graphs, Guest data capturing, CSV Export and third-party user data sync

User data synchronization: MailChimp List or scheduled periodic upload to FTP Server

Guest network and guest devices session, speed and time limits

Printable custom user/pass tickets with your custom titles, texts and validity settings

Custom user/pass tickets with three printing layout options: QR Login, Logo, Batch print

User/pass management from third-party software via API (HTTP API)

Prepaid Internet plans (time/data quotas) via the integrated payment portal accepting PayPal or credit cards

10-Star Guest Rating System with redirection capabilities to external websites such as TripAdvisor, Google Places etc.

Automated Email/SMS delivery for marketing purposes or delivery of individual Email/SMS discount coupons

Integrated Discount coupon code management system for use by employees

Limited access user accounts for User Manager and Coupon Code Management system

Centralized Remote management via the PointX CM system (sold separately with ControlX)

Free DDNS service provided for remote admin Web UI access

100% Software white-labeling option available (custom logos, texts)

Scheduled WiFi network and Ethernet port operation

Integrated Dual-Band 733 Mbps AC WiFi

VLAN Tagging (Protocols IEEE 802.1Q/C-Tag 802.11ad)

Works with any Access Point/AP Controller


SPECIFICATIONS

Hardware

Main CPU/RAM: 900MHz Quad-core / 1GB

Network CPU/RAM: 650MHz / 64MB

Buttons: Power On/Off, Factory Reset, 2.4GHz Radio, 5GHz Radio

Activity LEDs: Power, WAN/Internet Port, 2.4GHz Radio, 5GHz Radio, Guest Port, LAN Ports x4

Adjustable LEDs: Logo (intensity), Corner RGB (intensity, color)

Operating Temperature: -20°C to +60°C

Input Voltage: 24V 1.2A

Dimensions: 286x165x46mm

Weight: 850g


Ethernet

WAN Throughput: 100 Mbps

WAN Interfaces: 1x WAN/Internet 10/100M

LAN Interfaces: 4x LAN 10/100M

Guest Interfaces: 1x Guest Port 10/100M (PoE out)

PoE Out Voltage: 24V 0.5A


Wireless

Wireless Interfaces: 1x Dual Chain 2.4GHz 802.11b/g/n, 1x Single Chain 5GHz 802.11a/n/ac

Antennas Type: Integrated 360° 1.5dBi for 2.4GHz, Integrated 360° 2dBi for 5GHz

Maximum Tx Power: 19 dBm @ 2.4GHz 22 dBm @ 5GHz

Wireless Chips: QCA9531 (2.4GHz 802.11b/g/n), QCA9887 (5GHz 802.11a/n/ac)


Brand:
WAVERTECH
MPN:
WAC52
Rackmount:
SFP:
SFP+:
SFP28 (25G):
QSFP+:

Datasheet (Waver-SmartOne-Brochure.pdf, 4,598 Kb) [Λήψη]

User Guide (QS-SmartOne.pdf, 1,025 Kb) [Λήψη]

CE (CE-SmartOne.pdf, 91 Kb) [Λήψη]
